Do you know aluminum plastic composite panels? Alusign tells you!

1. Aluminum composite panel classification

There are many varieties of aluminum composite material, and they are a new type of material. Therefore, there is no uniform classification method, and it is usually classified according to the purpose, product function and surface decoration effect.

(1) Classified by purpose

a. Aluminum plastic composite panels for building curtain wall

The minimum thickness of the upper and lower aluminum plates is not less than 0.50 mm, and the total thickness is not less than 4 mm. The material of aluminum should meet the requirements of GB/T3880. Generally, aluminum alloy sheets of 3000, 5000 series should be used. The coating should be coated with fluorocarbon resin.

b. Exterior wall decoration and advertising aluminium composite panel

The upper and lower aluminum plates are made of rust-proof aluminum with a thickness of not less than 0.20 mm, and the total aluminum composite panel thickness is not less than 4 mm. The coating is typically a fluorocarbon coating or a polyester coating.

c. Indoor composite panel

The upper and lower aluminum plates generally adopt an aluminum plate having a thickness of 0.20 mm and a minimum thickness of not less than 0.10 mm, and the total aluminum composite panel thickness is generally 3 mm. The coating is polyester coated or acrylic coated.

(2) Classified by product function

a. Fireproof alucobond panel

The flame retardant core material is selected, and the combustion performance of the product reaches the flame retardant grade (B1 grade) or the non-combustible grade (A grade); at the same time, other performance indexes must also meet the technical specifications of the aluminum panel sheet.

b. Antibacterial mildew resistant composite sheet material

The antibacterial and bactericidal coating is applied to the aluminium composite material to control the microbial activity and ultimately kill the bacteria.

c. Antistatic composite metal panels

The antistatic aluminum composite sheet is coated with an anti-static coating to form an acm metal panel, and the surface resistivity is below 109 Ω, which is smaller than the surface resistivity of the ordinary acm material, so that static electricity is not easily generated, and dust in the air is not easily attached to the surface.

(3) Classification by surface decoration effect

a. Coated decorative composite sheets

A variety of decorative coatings can be applied to the surface of the aluminum panel. Commonly used are fluorocarbon, polyester, acrylic coatings, mainly including metallic, plain, pearlescent, fluorescentand other colors, with decorative effects.

b. Oxidized colored acm metal panels

The anodized and timely treatment of the aluminum alloy panel has a unique color such as rose red and bronze, which has a special decorative effect.

c. Film decorative acm panels

That is, the colored film is applied to the primed aluminum plate or directly to the degreased aluminum plate according to the set process conditions and the action of the adhesive. The main varieties are slats, wood boards and so on.

d. Color printed reynobond panels

Different patterns are printed on the transfer paper by advanced computer photo-printing technology, and various imitation natural patterns are printed on the aluminum composite material by thermal transfer technology. It can meet the designer's creativity and the owner's personalized choice.

e. Brushed aluminum composite panel

The aluminum alloy panel with brushed surface is common with gold wire drawing and silver wire drawing products, which bring different visual feelings.

f. Mirror composite metal panel

The surface of the aluminum alloy panel is polished to look like a mirror.

2. Specifications of composite sheet material

Common specifications for ordinary aluminum metal panels are as follows:
a. Total thickness: 3mm, 4mm, 6mm
b. Width: 1220mm, 1500mm
c. Length: 1000mm, 2440mm, 3000mm, 4000mm, 6000mm
d. The 1220*2440mm size aluminum plastic composite panel is called the standard board in the industry.

Above are some introduction about aluminum composite board. Do you have demand in aluminum composite material panels? Our Alusign aluminum composite panel can meet your requirements! You can send email to: [email protected] to get discount wholesale price and more product information. Of course, you can also leave your message here, and we will contact you soon.
